Nitrogen Gas Spring - HDG118-10

  • SPECIFICATIONS
  • MOUNTING OPTIONS
  • MAINTENANCE
  • PROTECTION
  • DOWNLOADS
  • FORCE CALCULATOR
  • DISTRIBUTORS
PRODUCT CODE
HDG118-10
  • Description:

    The HDG range is a compact bore sealed gas spring, giving maximum force for the cylinder diameter.

  • BODY DIAMETER:120 mm
  • PISTON DIAMETER:80 mm
  • INITIAL FORCE:11800 daN
  • MAXIMUM FORCE:12863 daN
  • STROKE:10 mm
  • L MIN:90 mm
  • LENGTH:100 mm
  • SAFETY MARGIN:3 mm
  • PCD:68 mm
  • TAPPED HOLE DIAMETER:M10
  • TAPPED HOLE DEPTH:10 mm
  • WEIGHT:5.52 Kg
  • MAX PRESSURE:150 Bar
  • MIN PRESSURE:25 Bar
  • MAX PISTON VELOCITY:0.8M/Sec

Features

Flexi Guide design
