Accuride DZ5306DO Heavy Duty Drawer Slides and Runners with Lock In and Hold Out

Name: Accuride DZ5306DO Heavy Duty Drawer Slides and Runners with Lock In and Hold Out
SKU: DZ5306DO

Only %1 left

SKU

DZ5306DO

More Information
Available Load Ratings	60Kg, 70Kg, 75Kg, 80Kg, 85Kg, 90Kg, 100Kg, 110Kg, 120Kg
Slide Lengths	300mm, 350mm, 400mm, 450mm, 500mm, 550mm, 600mm, 700mm, 790mm, 900mm, 1000mm, 1100mm
Travel Range	323mm, 373mm, 423mm, 473mm, 523mm, 573mm, 623mm, 723mm, 803mm, 923mm, 1023mm, 1123mm
Mounting Options	Cannot be Flat Mounted
Features	Hold Out (DO), Lock In
Extension	100%
Finish	Zinc Plate & Blue Passivate (DZ)
Height	53mm
Thickness	19.1mm
Brackets	Optional Screw In
Fixings Included	No
Sold as	Pairs
Model Series	5306

Accuride Datasheets

5306 DatasheetDownload

Catalogues

Download Accuride CatalogueDownload

Skip to the end of the images gallery

Skip to the beginning of the images gallery

BASIC PRICE £61.67

All prices exclude VAT

Slide Length

- Accuride limited lifetime guarantee

- DZ zinc plating salt spray tested to over 12hrs

- Please note the 900mm, 1000mm and 1100mm lengths available in this range of Accuride slides are made-to-order and it is Accuride's policy that orders placed for these cannot be cancelled. Furthermore due to them being a made to order product, or in other words, a custom product, we cannot accept returns for these lengths of slide within the DZ5306DO range.

- Need it in a hurry? Accuride Quickship is available (except the 900mm, 1000mm and 1100mm lengths)
