24.9x70 10mm travel with a force range of 4250N - 7300N
SKU
HDG0042-10
| Outside Dia. (mm) | 24.9mm |
|---|---|
| Piston Dia. (mm) | 12 |
| Travel (mm) | 10mm |
| Body Length (mm) | 60 |
| Free Length (mm) | 70 |
| Mounting Options | Drop-in Pocket, Front Flange, M6 Tapped Hole (strokes up to 25mm) |
| Charge Port | M6 |
| Tapped Hole Depth (mm) | 16 |
| Initial Force (N) | 4250 |
| Certification | ISO 9001:2015, PED 2014/68/EU |
£84.76
All prices exclude VAT
VOLUME DISCOUNTS
- QUANTITYPRICE
- 10 + £78.40
- 25 + £72.05
-
Product codeProduct DescriptionStock Status
-
HDG0042-1024.9x70 10mm travel with a force range of 4250N - 7300NChat or Contact us
