12x205 80mm travel threaded compression spring with an M16x2mm thread
SKU
MNE16-2-XXX-080
| Outside Dia. (mm) | 12mm |
|---|---|
| Piston Dia. (mm) | 6 |
| Travel (mm) | 80mm |
| Body Length (mm) | 125mm |
| Free Length (mm) | 205mm |
| Mounting Options | Threaded Pocket |
| Charge Port | M6 |
| Tapped Hole Depth (mm) | 5 |
| Initial Force (N) | 57N, 110N, 210N, 420N |
| Body Thread | M16x2 |
| Certification | ISO 9001:2015, PED 2014/68/EU |
£52.48
All prices exclude VAT
VOLUME DISCOUNTS
- QUANTITYPRICE
- 10 + £48.54
- 25 + £44.61
-
Product codeProduct DescriptionStock Status
-
MNE16-2-XXX-08012x205 80mm travel threaded compression spring with an M16x2mm threadChat or Contact us
