19x56 7mm travel mini compression spring
SKU
NG0-XXX-007
| Outside Dia. (mm) | 19mm |
|---|---|
| Piston Dia. (mm) | 8 |
| Travel (mm) | 7mm |
| Body Length (mm) | 49mm |
| Free Length (mm) | 56mm |
| Mounting Options | Drop-in Pocket, Front Flange, M6 Tapped Hole (strokes up to 25mm) |
| Charge Port | M6 |
| Tapped Hole Depth (mm) | 5 |
| Initial Force (N) | 300N, 500N, 700N, 900N |
| Certification | ISO 9001:2015, PED 2014/68/EU |
£63.66
All prices exclude VAT
VOLUME DISCOUNTS
- QUANTITYPRICE
- 10 + £58.89
- 25 + £54.11
-
Product codeProduct DescriptionStock Status
-
NG0-XXX-00719x56 7mm travel mini compression springChat or Contact us
