Accuride DS4180 Stainless Steel 304 Drawer Runners and Slides supporting up to 825Kg

Only %1 left
SKU
DS4180
More Information
Available Load Ratings 345Kg, 365Kg, 385Kg, 405Kg, 425Kg, 445Kg, 465Kg, 485Kg, 505Kg, 525Kg, 545Kg, 565Kg, 585Kg, 610Kg, 630Kg, 650Kg, 670Kg, 690Kg, 710Kg, 730Kg, 745Kg, 760Kg, 775Kg, 785Kg, 790Kg, 800Kg, 805Kg, 810Kg, 815Kg, 825Kg
Slide Lengths 500mm, 550mm, 600mm, 650mm, 700mm, 750mm, 800mm, 850mm, 900mm, 950mm, 1000mm, 1050mm, 1100mm, 1150mm, 1200mm, 1250mm, 1300mm, 1350mm, 1400mm, 1450mm, 1500mm, 1550mm, 1600mm, 1650mm, 1700mm, 1750mm, 1800mm, 1850mm, 1900mm, 1950mm, 2000mm
Travel Range 500mm, 550mm, 600mm, 650mm, 700mm, 750mm, 800mm, 850mm, 900mm, 950mm, 1000mm, 1050mm, 1100mm, 1150mm, 1200mm, 1250mm, 1300mm, 1350mm, 1400mm, 1450mm, 1500mm, 1550mm, 1600mm, 1650mm, 1700mm, 1750mm, 1800mm, 1850mm, 1900mm, 1950mm, 2000mm
Mounting Options Suitable for Flat Mounting
Features Corrosion Resistance
Extension 100%
Finish Stainless Steel 304 (DS)
Height 80mm
Thickness 35mm
Brackets Optional Screw In
Fixings Included No
Sold as Individually
Model Series 4180
Catalogues
main product photo
BASIC PRICE £782.48
All prices exclude VAT

- Accuride limited lifetime guarantee

- DS stainless steel 304 salt spray tested to 500hrs

- Please note the DS4180 range of Accuride slides is made-to-order and it is Accuride's policy that orders placed for the DS4180 cannot be cancelled. Furthermore due to it being a made to order product, or in other words, a custom product, we cannot accept returns for this slide or any slides within the 4180 range.

- A die cast zinc version of this slide (DZ4180) is also available .

Metrol Springs
DS4180
/media/catalog/product/4/1/4180_1.jpg
Add to Favourites
Note: adds the product to your favourites list in your account
  • Product code
    Product Description
    Stock Status
  • DS4180-080-035-0050
    Slide Length: 500mm, Sold as: Individually
  • DS4180-080-035-0055
    Slide Length: 550mm, Sold as: Individually
  • DS4180-080-035-0060
    Slide Length: 600mm, Sold as: Individually
  • DS4180-080-035-0065
    Slide Length: 650mm, Sold as: Individually
  • DS4180-080-035-0070
    Slide Length: 700mm, Sold as: Individually
  • DS4180-080-035-0075
    Slide Length: 750mm, Sold as: Individually
  • DS4180-080-035-0080
    Slide Length: 800mm, Sold as: Individually
  • DS4180-080-035-0085
    Slide Length: 850mm, Sold as: Individually
  • DS4180-080-035-0090
    Slide Length: 900mm, Sold as: Individually
  • DS4180-080-035-0095
    Slide Length: 950mm, Sold as: Individually
  • DS4180-080-035-0100
    Slide Length: 1000mm, Sold as: Individually
  • DS4180-080-035-0105
    Slide Length: 1050mm, Sold as: Individually
  • DS4180-080-035-0110
    Slide Length: 1100mm, Sold as: Individually
  • DS4180-080-035-0115
    Slide Length: 1150mm, Sold as: Individually
  • DS4180-080-035-0120
    Slide Length: 1200mm, Sold as: Individually
  • DS4180-080-035-0125
    Slide Length: 1250mm, Sold as: Individually
  • DS4180-080-035-0130
    Slide Length: 1300mm, Sold as: Individually
  • DS4180-080-035-0135
    Slide Length: 1350mm, Sold as: Individually
  • DS4180-080-035-0140
    Slide Length: 1400mm, Sold as: Individually
  • DS4180-080-035-0145
    Slide Length: 1450mm, Sold as: Individually
  • DS4180-080-035-0150
    Slide Length: 1500mm, Sold as: Individually
  • DS4180-080-035-0155
    Slide Length: 1550mm, Sold as: Individually
  • DS4180-080-035-0160
    Slide Length: 1600mm, Sold as: Individually
  • DS4180-080-035-0165
    Slide Length: 1650mm, Sold as: Individually
  • DS4180-080-035-0170
    Slide Length: 1700mm, Sold as: Individually
  • DS4180-080-035-0175
    Slide Length: 1750mm, Sold as: Individually
  • DS4180-080-035-0180
    Slide Length: 1800mm, Sold as: Individually
  • DS4180-080-035-0185
    Slide Length: 1850mm, Sold as: Individually
  • DS4180-080-035-0190
    Slide Length: 1900mm, Sold as: Individually
  • DS4180-080-035-0195
    Slide Length: 1950mm, Sold as: Individually
  • DS4180-080-035-0200
    Slide Length: 2000mm, Sold as: Individually
CAD Files
Accuride CAD files
  • 4180-080-035-0050 STEP FILE
  • 4180-080-035-0055 STEP FILE
  • 4180-080-035-0060 STEP FILE
  • 4180-080-035-0065 STEP FILE
  • 4180-080-035-0070 STEP FILE
  • 4180-080-035-0075 STEP FILE
  • 4180-080-035-0080 STEP FILE
  • 4180-080-035-0085 STEP FILE
  • 4180-080-035-0090 STEP FILE
  • 4180-080-035-0095 STEP FILE
  • 4180-080-035-0100 STEP FILE
  • 4180-080-035-0105 STEP FILE
  • 4180-080-035-0110 STEP FILE
  • 4180-080-035-0115 STEP FILE
  • 4180-080-035-0120 STEP FILE
  • 4180-080-035-0125 STEP FILE
  • 4180-080-035-0130 STEP FILE
  • 4180-080-035-0135 STEP FILE
  • 4180-080-035-0140 STEP FILE
  • 4180-080-035-0145 STEP FILE
  • 4180-080-035-0150 STEP FILE
  • 4180-080-035-0155 STEP FILE
  • 4180-080-035-0160 STEP FILE
  • 4180-080-035-0165 STEP FILE
  • 4180-080-035-0170 STEP FILE
  • 4180-080-035-0175 STEP FILE
  • 4180-080-035-0180 STEP FILE
  • 4180-080-035-0185 STEP FILE
  • 4180-080-035-0190 STEP FILE
  • 4180-080-035-0195 STEP FILE
  • 4180-080-035-0200 STEP FILE
