Accuride DZ4180-80 Drawer Runners and Slides supporting up to 980Kg

Only %1 left
SKU
DZ4180
More Information
Available Load Ratings 410Kg, 434Kg, 458Kg, 482Kg, 506Kg, 530Kg, 554Kg, 578Kg, 602Kg, 626Kg, 650Kg, 674Kg, 698Kg, 722Kg, 746Kg, 770Kg, 794Kg, 818Kg, 842Kg, 866Kg, 890Kg, 905Kg, 920Kg, 930Kg, 940Kg, 950Kg, 955Kg, 960Kg, 970Kg, 980Kg
Slide Lengths 500mm, 550mm, 600mm, 650mm, 700mm, 750mm, 800mm, 850mm, 900mm, 950mm, 1000mm, 1050mm, 1100mm, 1150mm, 1200mm, 1250mm, 1300mm, 1350mm, 1400mm, 1450mm, 1500mm, 1550mm, 1600mm, 1650mm, 1700mm, 1750mm, 1800mm, 1850mm, 1900mm, 1950mm, 2000mm
Travel Range 500mm, 550mm, 600mm, 650mm, 700mm, 750mm, 800mm, 850mm, 900mm, 950mm, 1000mm, 1050mm, 1100mm, 1150mm, 1200mm, 1250mm, 1300mm, 1350mm, 1400mm, 1450mm, 1500mm, 1550mm, 1600mm, 1650mm, 1700mm, 1750mm, 1800mm, 1850mm, 1900mm, 1950mm, 2000mm
Mounting Options Suitable for Flat Mounting
Extension 100%
Finish Zinc Plate & Blue Passivate (DZ)
Height 80mm
Thickness 35mm
Fixings Included No
Sold as Individually
Model Series 4180
Catalogues
Accuride Datasheets
main product photo
BASIC PRICE £392.54
All prices exclude VAT

- Accuride limited lifetime guarantee

- DZ zinc plating salt spray tested to over 220hrs

- Please note the DZ4180 range of Accuride slides is made-to-order and it is Accuride's policy that orders placed for the DZ4180 cannot be cancelled. Furthermore due to it being a made to order product, or in other words, a custom product, we cannot accept returns for this slide or any slides within the 4180 range.

- A stainless steel version of this slide (DS4180) is also available.

Metrol Springs
DZ4180
/media/catalog/product/4/1/4180.jpg
Add to Favourites
Note: adds the product to your favourites list in your account
  • Product code
    Product Description
    Stock Status
  • DZ4180-080-035-0165U
    Slide Length: 1650mm, Sold as: Individually
  • DZ4180-080-035-0170U
    Slide Length: 1700mm, Sold as: Individually
  • DZ4180-080-035-0175U
    Slide Length: 1750mm, Sold as: Individually
  • DZ4180-080-035-0180U
    Slide Length: 1800mm, Sold as: Individually
  • DZ4180-080-035-0185U
    Slide Length: 1850mm, Sold as: Individually
  • DZ4180-080-035-0190U
    Slide Length: 1900mm, Sold as: Individually
  • DZ4180-080-035-0195U
    Slide Length: 1950mm, Sold as: Individually
  • DZ4180-080-035-0200U
    Slide Length: 2000mm, Sold as: Individually
  • DZ4180-080-035-0050U
    Slide Length: 500mm, Sold as: Individually
  • DZ4180-080-035-0055U
    Slide Length: 550mm, Sold as: Individually
  • DZ4180-080-035-0060U
    Slide Length: 600mm, Sold as: Individually
  • DZ4180-080-035-0065U
    Slide Length: 650mm, Sold as: Individually
  • DZ4180-080-035-0070U
    Slide Length: 700mm, Sold as: Individually
  • DZ4180-080-035-0075U
    Slide Length: 750mm, Sold as: Individually
  • DZ4180-080-035-0080U
    Slide Length: 800mm, Sold as: Individually
  • DZ4180-080-035-0085U
    Slide Length: 850mm, Sold as: Individually
  • DZ4180-080-035-0090U
    Slide Length: 900mm, Sold as: Individually
  • DZ4180-080-035-0095U
    Slide Length: 950mm, Sold as: Individually
  • DZ4180-080-035-0100U
    Slide Length: 1000mm, Sold as: Individually
  • DZ4180-080-035-0105U
    Slide Length: 1050mm, Sold as: Individually
  • DZ4180-080-035-0110U
    Slide Length: 1100mm, Sold as: Individually
  • DZ4180-080-035-0115U
    Slide Length: 1150mm, Sold as: Individually
  • DZ4180-080-035-0120U
    Slide Length: 1200mm, Sold as: Individually
  • DZ4180-080-035-0125U
    Slide Length: 1250mm, Sold as: Individually
  • DZ4180-080-035-0130U
    Slide Length: 1300mm, Sold as: Individually
  • DZ4180-080-035-0135U
    Slide Length: 1350mm, Sold as: Individually
  • DZ4180-080-035-0140U
    Slide Length: 1400mm, Sold as: Individually
  • DZ4180-080-035-0145U
    Slide Length: 1450mm, Sold as: Individually
  • DZ4180-080-035-0150U
    Slide Length: 1500mm, Sold as: Individually
  • DZ4180-080-035-0155U
    Slide Length: 1550mm, Sold as: Individually
  • DZ4180-080-035-0160U
    Slide Length: 1600mm, Sold as: Individually
CAD Files
Accuride CAD files
  • 4180-080-035-0165 STEP FILE
  • 4180-080-035-0170 STEP FILE
  • 4180-080-035-0175 STEP FILE
  • 4180-080-035-0180 STEP FILE
  • 4180-080-035-0185 STEP FILE
  • 4180-080-035-0190 STEP FILE
  • 4180-080-035-0195 STEP FILE
  • 4180-080-035-0200 STEP FILE
