19x56 13mm travel with a force range of 1700N - 2800N
SKU
EX0170-013
| Outside Dia. (mm) | 19mm |
|---|---|
| Piston Dia. (mm) | 11 |
| Travel (mm) | 13mm |
| Body Length (mm) | 43 |
| Free Length (mm) | 56 |
| Mounting Options | Drop-in Pocket, Front Flange, M6 Tapped Hole (strokes up to 25mm) |
| Charge Port | M6 |
| Tapped Hole Depth (mm) | 5 |
| Initial Force (N) | 1700 |
| Certification | ISO 9001:2015, PED 2014/68/EU |
£69.22
All prices exclude VAT
VOLUME DISCOUNTS
- QUANTITYPRICE
- 10 + £64.02
- 25 + £58.83
-
Product codeProduct DescriptionStock Status
-
EX0170-01319x56 13mm travel with a force range of 1700N - 2800NChat or Contact us
