24.9x56 13mm travel with a force range of 3200N - 5000N
SKU
EX0320-013
| Outside Dia. (mm) | 24.9mm |
|---|---|
| Piston Dia. (mm) | 15 |
| Travel (mm) | 13mm |
| Body Length (mm) | 43 |
| Free Length (mm) | 56 |
| Mounting Options | Drop-in Pocket, End Support, Front Flange, M6 Tapped Hole (strokes up to 25mm) |
| Charge Port | M6 |
| Tapped Hole Depth (mm) | 5 |
| Initial Force (N) | 3200 |
| Certification | ISO 9001:2015, PED 2014/68/EU |
£59.89
All prices exclude VAT
VOLUME DISCOUNTS
- QUANTITYPRICE
- 10 + £55.40
- 25 + £50.91
-
Product codeProduct DescriptionStock Status
-
EX0320-01324.9x56 13mm travel with a force range of 3200N - 5000NChat or Contact us
