24.9x195 80mm travel with a force range of 3200N - 5300N
SKU
EX0320-080
| Outside Dia. (mm) | 24.9mm |
|---|---|
| Piston Dia. (mm) | 15 |
| Travel (mm) | 80mm |
| Body Length (mm) | 115 |
| Free Length (mm) | 195 |
| Mounting Options | Drop-in Pocket, End Support, Front Flange, M6 Tapped Hole (strokes up to 25mm) |
| Charge Port | M6 |
| Tapped Hole Depth (mm) | 5 |
| Initial Force (N) | 3200 |
| Certification | ISO 9001:2015, PED 2014/68/EU |
£71.56
All prices exclude VAT
VOLUME DISCOUNTS
- QUANTITYPRICE
- 10 + £66.20
- 25 + £60.83
-
Product codeProduct DescriptionStock Status
-
EX0320-08024.9x195 80mm travel with a force range of 3200N - 5300NChat or Contact us
