EX0500-013 Nitrogen Gas Spring, 500daN Force
SKU
EX0500-013
| Body Dia. (mm) | 38 |
|---|---|
| Piston Dia. (mm) | 20 |
| Stroke (mm) | 13 |
| L Min (mm) | 43 |
| Full Length (mm) | 56 |
| Mounting Options | End Support, Front Flange, Tapped Hole, Square Flange, Square Front Flange |
| Charge Port | M6 |
| Tapped Hole Depth (mm) | 6 |
| Initial Force (N) | 5000 |
| Max Force (N) | 6890 |
| Certification | ISO 9001:2015, PED 2014/68/EU |
Product Enquiry
The EX0500-013 is part of the powerful EX range. It has an initial force of 500daN with the maximum being 746daN. As well as a weight of 0.26kg, its overall length of 56mm
-
Product codeProduct DescriptionStock Status
-
EX0500-013EX0500-013 Nitrogen Gas Spring, 500daN ForceChat or Contact us
