HS-G-EX1000-025 Nitrogen Gas Spring, 920daN Force
SKU
HS-G-EX1000-025
| Body Dia. (mm) | 16.1-20mm |
|---|---|
| Mounting Options | End Support, Front Flange, Square Flange, Square Front Flange |
| Tapped Hole Depth (mm) | 16mm |
| Certification | PED 2014/68/EU |
Product Enquiry
The HS-G-EX1000-025 is an extended version of the HS-EX hot stamping gas spring with deeper tapped holes in the base. It features a maximum spring force of 1420daN and a weight of 0.63kg
-
Product codeProduct DescriptionStock Status
-
HS-G-EX1000-025HS-G-EX1000-025 Nitrogen Gas Spring, 920daN ForceChat or Contact us
