HS-NG3000-300 Nitrogen Gas Spring, 3000daN Force
SKU
HS-NG3000-300
| Body Dia. (mm) | 95 |
|---|---|
| Piston Dia. (mm) | 50 |
| Stroke (mm) | 300 |
| L Min (mm) | 420 |
| Full Length (mm) | 720 |
| Mounting Options | Base Plate, End Support, Front Flange, Tapped Hole, Square Flange, Square Front Flange |
| Charge Port | G1/8 |
| Tapped Hole Depth (mm) | 13 |
| Initial Force (N) | 30000 |
| Max Force (N) | 48000 |
| Certification | PED 2014/68/EU |
Product Enquiry
The HS-NG3000-300 is our hot stamping gas spring designed for durability. It features a maximum spring force of 4800daN and a weight of 15.30kg
