Nitrogen Gas Spring - MX4200-063
SKU
MX4200-063
| Body Dia. (mm) | 95 |
|---|---|
| Piston Dia. (mm) | 60 |
| Stroke (mm) | 63 |
| L Min (mm) | 183 |
| Full Length (mm) | 246 |
| Mounting Options | End Support, Front Flange, Square Flange, Square Front Flange |
| Charge Port | G1/8 |
| Tapped Hole Depth (mm) | 13 |
| Initial Force (N) | 42000 |
| Certification | ISO 9001:2015, PED 2014/68/EU |
Product Enquiry
The MX Range is a rod sealed gas spring that combines the power of the EX range, with the available stroke lengths of the ISNG range.
-
Product codeProduct DescriptionStock Status
-
MX4200-063Nitrogen Gas Spring - MX4200-063Chat or Contact us
